Comfort dehumidifier TTK 120 S

Solid, reliable, powerful – a classic...

A real classic: For many years this low-maintenance high-quality dehumidifier has served thousands of happy customers all over Europe well.

The design of the TTK 120 S is utterly reliable and thus equally suitable for the use in larger living, storage or workshop spaces.

The robust device with its solid metal plastic composite housing distinguishes itself through an excellent workmanship and reliably protects your objects against corrosion and moisture with a daily dehumidification performance of up to 35 litres.

The dehumidifier works in hygrostat-controlled automatic operation, is provided with an effective hot gas automatic defrosting and and also suitable for permanent drying in unattended rooms. The anti-bacterial filter holds back fluff, dust or animal hair and prevents bacteria growth.

Special features:

  • Hot gas automatic defrosting on a 30 minute cycle
  • Ideal for room sizes of up to 238 m³
  • Dehumidifier manufactured in the EU with solid metal plastic composite housing
Click to enlarge the chart in a new window

Which device is suited for which room size? For each comfort dehumidifier a specific performance chart regarding the suitability is to be found here. From it you can read the room size directly with area and volume ranges. Click to enlarge the chart in a new window...

Standard features:

  • Adjustable hygrostat for constant monitoring of relative humidity. When exceeded, the device is automatically activated. As soon as the desired humidity value is reached, the compressor automatically switches off.
  • Filling level warning lamp to indicate a full water tank
  • Overflow protection with automatic switch-off
  • Connection for external condensation drain
  • Swivel casters with parking brakes
  • Easily accessible air filter, easy to clean. Filters animal hair, fluff, lint, dust and prevents spread of bacteria.
Comfort dehumidifier TTK 120 S
Comfort dehumidifier TTK 120 S
Comfort dehumidifier TTK 120 S


Shop

Technical data

Technical data
General information
  Article number 1.120.000.122
Dehumidification performance
  At 30 °C / 80 % RH [l/24h] 27
  Max. [l/24h] 35
Air flow rate
  Level Max. [m³/h] 510
Recommended room size construction drying
  120
  48
Recommended room size dry keeping
  238
  95
Ambient conditions
  Min. temperature range [°C] 5
  Max. temperature range [°C] 43
  Min. humidity range [% RH] 40
  Max. humidity range [% RH] 100
Electrical values
  Mains connection 230 V/50 Hz
  Nominal current consumption [A] 2.1
  Power input [kW] 0.4
  Recommended fusing [A] 10
  Required current starting phase [A]
Electric connection
  Connection plug CEE 7/7
  Cable length [m] 2.8
Compressor
  Reciprocating piston compressor
  Rotary piston compressor
  Type of cooling agent R-134a
  Amount of refrigerant [g] 344
  GWP factor 1,430
  CO2 equivalent 0.492 t
Water tank
  Contents in [l] 8
Sound values
  Distance 1 m [dB(A)] 59
Dimensions
  Length (packaging excluded) [mm] 362
  Width (packaging excluded) [mm] 380
  Height (packaging excluded) [mm] 605
Weight
  (packaging excluded) [kg] 23.5
Equipment, features and functions
Automatic defrost system
  Hot gas
  Electronic
Automatic dehumidification
  Non-stop dehumidification
  Analogue hygrostat
  Hygrostat-controlled
  Electronic hygrostat
  Program-controlled
Fan
  axial
  Radial
  stages 1
Condensate tank monitoring
  Container available
  Shut-off when full
  Indicator container full
Room air filter
  Readily accessible
  Cleanable
  Ionizer selectable
Timer function
  Switch-off time can be preselected
  Switch-on time preselectable
Functions and features
  Laundry drying function
  Selectable ionisation
  Internal drying function
  Child lock
  Noiseless night operation in whisper mode
  Comfort button
Operating hours counter
  Operating hours counter
  Power meter
Mobility
  Carry/transport handle(s)
  Plastic wheels
  Swivel casters with parking brakes
  Rubber-tyred metal wheels
  Non-marking full-rubber wheels
  Adjustable bar handle
Condensate drain
  Hose connection possible
  Hose included in the scope of delivery
  Recommended hose size [mm]
  Condensate pump
  Recommended hose size [mm] 10
Control panel
  Digital display
  Protective bar
Shelf life
  stackable
Adjustable air discharge direction
  manual
  Swing function
Housing design
  Metal plastic composite housing
  Plastics
  Steel coated
  Stainless steel
  Aluminium

 standard equipment

 optionally available

 not available
