Dehumidifier TTK 54 E
Home Comfort
  1. Products & Services
  2. Machinery - HomeComfort
  3. Dehumidification
  4. Condensation dehumidifier of the TTK-series
  5. TTK 54 E (2019)

Comfort dehumidifier TTK 54 E

The elegant solution for the use at home and in the office

TTK 54 E - perspective view
TTK 54 E - side view
TTK 54 E - front view

Comfort, design and a high air flow rate

You will hardly find a similarly successful implementation of pure design as with the TTK 54 E. Elegantly rounded edges harmonize with an elegant white, and the discreet recessed handles point the way to the practical equipment details of this flagship dehumidifier.

With its manifold features, the TTK 54 E is entirely trimmed for high performance. This is, for example, reflected by its four operating modes: Here, the dehumidifier offers hygrostat-controlled automatic dehumidification with target values that can be set from 35 to 85 % relative humidity in convenient steps of 5 % – including an on-demand turbo blower!

A popular alternative to the automatic dehumidification function is the comfort function of the TTK 54 E, which automatically controls the humidity level to a comfortable value depending on the temperature. Further operating modes available are the laundry drying function and the continuous operation function.

Comfort function: Temperature-dependent dehumidification

For a perfect indoor climate, the room temperature and humidity level must be synchronized. And this is exactly where the temperature-dependent dehumidification comes in. The device adjusts the humidity level to the optimum value depending on the temperature. The comfort function is particularly advisable when utilizing program-controlled heating systems. If the room temperature changes in the day or night, the dehumidifier adapts its dehumidification performance in a fully automated fashion.

Useful features

When it come to its dehumidification performance, the TTK 54 E is at its most impressive. Accumulating up to 16 litres of condensate in 24 hours, the device is a truly reliable partner in keeping living spaces and offices sized up to approx. 30 m² dry.
Another special feature of this excellent dehumidifier is the window that allows for a visual check of the water tank's filling level. Naturally, the remaining equipment features of this dehumidifier also meet the high standards of the HomeComfort series. These features include a practical timer function, a filling level warning light to indicate a full water tank and an overflow protection with automatic switch-off.

The variety of functions is completed by the washable air filter and the integrated drainage connection allowing for unattended continuous operation. The convenient cable holder, the integrated carrying handles and the steerable wheels turn any change of location into a simple exercise.

Auto restart function

Auto restart function

In case of an unexpected switch-off due to a power interruption, the auto restart function (or “Memory function”) makes the device restart with the previously selected setting as soon as the power supply has been restored. This makes the dehumidifier also suitable for combined use with a timer.

TTK 54 E - dimensions
TTK 54 E - laundry drying function
TTK 54 E - optimum humidity level in the bedroom

Gentle laundry drying with dehumidifiers

Apart from ambient air dehumidification, a dehumidifier can be conveniently used for drying laundry – either in an assisting way or as a full replacement for a conventional dryer. The laundry drying function (also referred to as clothes drying mode or SuperDry function) is comparable to traditional air drying outside.

Dehumidifiers offer the benefit of drying the laundry as gently as in the nature outside. Colours retain their brilliance and the life span of clothes is longer than with conventional dryers – and all this with a substantially lower power consumption.

Furthermore, even sensitive materials such as wool, silk or synthetic fibres can be dried without any problems. In contrast to pure air drying, the laundry feels much softer and more pleasant on your skin.

Laundry drying can also be performed with dehumidifiers without an additional laundry drying function. The target value of the air humidity must then be set in accordance with the desired residual humidity:

Cupboard dry: 46 % of relative air humidity

Iron dry: 58 % of relative air humidity

Skin dry: 65 % of relative air humidity

Laundry function
Environmentally friendly refrigerant R290

Propane (R290) as environmentally friendly refrigerant in dehumidifiers

Every year, several million tonnes of environmentally harmful CO2emissions (greenhouse gases) are emitted into the air by synthetic refrigerants. For this reason, the utilization of alternative refrigerants has become one of our key objectives. By using propane (R290) as refrigerant, this dehumidifier makes a valuable contribution to protecting our climate.

The natural refrigerant propane (R290) is an organic compound belonging to the group of hydrocarbons. Unlike synthetic refrigerants the environmentally friendly propane (R290) comes with neither ozone depletion potential (ODP = 0) nor a noteworthy greenhouse effect (GWP = 3).

Additional bonus for the environment: Owing to its excellent thermodynamic properties, propane (R290) is a particularly energy-efficient refrigerant thereby additionally reducing your energy costs.

TTK 54 E – special equipment features

The operating panel of the TTK 54 E is provided with a clear design and is easy to understand. The digital display for example shows you the current relative humidity level in the room.
TTK 54 E control panel
The easily removable air filter retains lint and animal hair and can be quickly and easily wiped or washed out.
TTK 54 E air filter
The removable water tank is provided with a storage capacity of 3 litres and a fill level window. The device stops automatically when the tank is full and indicates this via LED.
TTK 54 E water tank
In order to continuously drain the condensation water, a pipe can be connected on the rear of the device. The power cable can be wound up properly and clamped in the mounting bracket.
TTK 54 E rear view
By the automatic coordination of room temperature and air humidity, the comfort function provides for a perfect feel-good ambience. Depending on the temperature prevailing in the room in each case, the humidity level is regulated automatically to a specially pleasant 45%, 50% or 55%.
TTK 54 E comfort function
Use the practical timer function to switch the device after a defined number of hours (up to maximally 24 h) on or off. The timer can be programmed in increments of 0.5 hours (0 to 10 h) or in increments of 1 hour (10 to 24 h). The timer prevents unnecessary operating periods and allows you to adapt the dehumidification to your individual rhythm of life.
TTK 54 E timer function
The TTK 54 E may also be used as room air laundry dryer to dry wet laundry in living spaces or utility rooms. In this way, you speed up the drying process of the clothes and prevent the humidity contained on the clothes from condensing in the room and from becoming a hotbed for mould.
TTK 54 E laundry drying function
In the permanent mode, the TTK 54 E dehumidifies the room air in continuous operation. This is especially suitable for cellar or storage spaces which are subjected to mould formation by excess humidity. To avoid that you constantly have to drain the water tank, a condensate drain hose can be connected.
TTK 54 E permanent mode
Whether at home, in the office or in the bedroom – with its comfort operation for the temperature-dependent automatic humidity control, the display of the relative humidity level and its laundry drying and timer function, the dehumidifier TTK 54 E provides for a perfect indoor climate at all times.
TTK 54 E in the office
In order to prevent the formation of unwelcome mould that is dangerous to your health in cellars, hobby rooms or on cool corners and walls exposed to dampness in the first place, we recommend using a dehumidifier continuously and right from the start.
TTK 54 E in the developed cellar

A few practical benefits:

  • Hygrostat-controlled automatic dehumidification system with target value preselection between 35 and 85 % RH in steps of 5 %
  • When the desired humidity level is reached, the compressor switches off automatically. The fan keeps running. When the value is exceeded, the device is automatically activated.
  • Comfort mode for temperature-dependent automatic humidity control for an optimum room climate at all times
  • Continuous mode
  • Auto restart function to be used in combination with an external timer
  • Display of the relative humidity level
  • Easily accessible air filter, easy to clean. Filters animal hair, fluff, lint, dust as well as preventing bacterial growth.
  • Laundry function
  • Timer function
  • Automatic air circulation defrost system
  • Connection for external condensate drain
  • 2 fan stages
  • Filling level warning light to indicate a full water tank
  • Overflow protection with automatic switch-off
Tested for safety

Benefit from the Trotec brand quality guaranteeing high value, safety and functionality. Via the registered GS mark the inspection authority TÜV SÜD certifies that, if used foreseeably and as intended, the device does not pose a risk to the health and safety of the user.

Room size suitability TTK 54 E

Which device to use for which room size?

Here you find a specific performance chart for the suitability of each comfort dehumidifier. It indicates the room size in combination with an area and volume scale.
Click to enlarge in a new window ...

Product finder for dehumidifiers

We help you find the suitable dehumidifier that meets your requirements!

With our product finder you can quickly and easily choose the ideal dehumidifier for your application scenario.
Click here to go directly to the product finder

Thermohygrometer BZ05 and design weather station BZ06

Our recommendation for climate control:

The room thermohygrometer BZ05
Simultaneous display of room temperature, humidity level and time or date as well as an additional feel-good indication.

The design weather station BZ06
Simultaneous indication of room temperature, humidity level, date, time, weekday and symbolic weather forecast. Supplies helpful information for preventing mould growth.

Adsorption, condensation or Peltier dehumidifier?

Trotec, your dehumidification expert, has compiled the most important facts in a reader-friendly overview!

Direct link to "Practical knowledge of dehumidifiers" ... ...


Buy

Technical data

Technical data
General information
  Article number 1.120.000.044
Dehumidification performance
  At 30 °C / 80 % RH [l/24h] 14
  Max. [l/24h] 16
Air flow rate
  Level Max. [m³/h] 150
Recommended room size construction drying


Recommended room size dry keeping
  78
  31
Ambient conditions
  Min. temperature range [°C] 5
  Max. temperature range [°C] 32
  Min. humidity range [% RH] 35
  Max. humidity range [% RH] 85
Electrical values
  Mains connection 220 - 240 V/50 Hz
  Nominal current consumption [A] 2.2
  Power input [kW] 0.43
  Recommended fusing [A] 12
Electric connection
  Connection plug CEE 7/7
  Cable length [m] 1.6
Compressor
  Reciprocating piston compressor
  Rotary piston compressor
  Minimum room size [m²] 4
  Type of cooling agent R290
  Amount of refrigerant [g] 75
  GWP factor 3
  CO2 equivalent 0.00023 t
  Pressure suction side [MPa] 1
  Pressure outlet side [MPa] 2.6
Water tank
  Contents in [l] 3
Sound values
  Distance 1 m [dB(A)] 46
Dimensions
  Length (packaging excluded) [mm] 245
  Width (packaging excluded) [mm] 350
  Height (packaging excluded) [mm] 510
Weight
  (packaging excluded) [kg] 15
Equipment, features and functions
Automatic defrost system
  Air circulation / electronic
  Hot gas
Automatic dehumidification
  Non-stop dehumidification
  Electronic hygrostat
  Hygrostat-controlled
  Analogue hygrostat
  Program-controlled
Fan
  Radial
  axial
  stages 3
Condensate tank monitoring
  Container available
  Indicator container full
  Shut-off when full
Room air filter
  Readily accessible
  Cleanable
  Ionizer selectable
Timer function
  Switch-on time preselectable
  Switch-off time can be preselected
Functions and features
  Laundry drying function
  Comfort button
  Display of the relative humidity level
  Continuous operation
  Fan rundown function
  Internal drying function
  Child lock
  Noiseless night operation in whisper mode
  Selectable ionisation
Mobility
  Carry/transport handle(s)
  Plastic wheels
  Rubber-tyred metal wheels
  Non-marking full-rubber wheels
  Swivel casters with parking brakes
  Adjustable bar handle
Condensate drain
  Hose connection possible
  Hose included in the scope of delivery
  Condensate pump
  Recommended hose size [mm] 14
Control panel
  Protective bar
  Digital display
  Membrane keys
Adjustable air discharge direction
  Swing function
  manual
Housing design
  Plastics
  Steel coated
  Stainless steel
  Metal plastic composite housing
  Aluminium

 standard equipment

 optionally available

 not available
