Deep well pump TDP 750 E

Powerful 1,000 W stainless steel pump with a flow rate of up to 5,100 litres of clear water per hour

FREE SERVICE WATER FOR HOUSE AND GARDEN

The deep well pump TDP 750 E with its housing made of corrosion-resistant stainless steel is the perfect assistant when it comes to reliably conveying clear water from wells, reservoirs or shafts. This way, you can operate green spaces, garden areas and other consumptive points in the house with free service water which allows you to save many cubic metres of expensive tap water year after year. The powerful pump with 1,000 W transports up to 5,100 litres of water per hour from a depth of up to 50 metres (max. delivery head).

Good to know: In general, deep well pumps or submersible pressure pumps are designed for delivering water from great depths. Depending on the delivery head and flow rate, the pumps are available in different versions and performance levels.

Water galore, indoors and outdoors

The TDP 750 E is equipped with a stainless steel dirt strainer that filters out potential contaminations in the water caused by suspended matter and dirt particles from a size of 1.8 mm (based on a solids content of 0.15 % in one tonne of water). This allows you to use the conveyed clear water complementary to the domestic water supply, e.g. for the washing machine, flushing the toilet or for washing dishes and cleaning. As a matter of course, you can also water your flower or kitchen gardens, your flower beds and boxes on the your balcony and your lawn with the precious resource all summer long.

ECOLOGICAL AND ECONOMICAL

It is a good and profitable idea to include available water sources into your daily water demand, not only with regard to global warming and the trend towards a greater frequency of hotter and drier summers. Especially if you are one of the lucky ones to have a well, a well hole or a water shaft on your property. Particularly for irrigating green spaces, for washing your dishes, laundry or for cleaning, you can make perfect use of this available natural resource while permanently saving expensive tap water. By the way, this is also how you will protect the environment, since the tap water acquires its high drinking quality only after complex chemical treatments. The less chemicals are used, the better.

Trotec's deep well pumps are really efficient devices that have been specially designed as submersible pressure pumps. Due to their particular construction and high-quality technology, they can be used in very narrow drilled wells with a minimum diameter of 12.5 centimetres. The standard equipment contains a connection cable of 23 metres length, providing an unproblematic water transport from great depths. The integrated suspension eyes allow to easily lower the pumps down the well, cistern, drainage shaft or similar. Like all submersible pressure pumps our deep well pumps, too, are optionally suited for either fixed installation or the mobile application at various sites.

Saving tip: In the long run self-pumped water saves money. The investment for installing a well in your own garden (if not already present) will quickly redeem itself over the course of only a few years – depending on the individual usage intensity. Specialized well builders can help you in the planning and construction phase of your own garden well.

PLUG & PLAY – THE CONVENIENT AND PRACTICAL SOLUTION

The power supply is implemented via the 23 m underwater cable that is included in the scope of delivery. Thanks to the Plug & Play connection, the TDP 750 E is immediately ready for use. In order to lower the pump into the pumping medium easily and safely, the housing is equipped with two stable suspension eyes. The optionally available spacer foot that can be mounted enables to set the deep well pump into the prepared indentation in the ground, e.g. in drainage shafts or wells. However, the bottom of the well must be clean and free from dirt in this case.

High-quality materials combined with modern technology

A stable housing made of stainless steel, a maintenance-free copper motor and a robust pressure connection with brass insert make the TDP 750 E an extremely durable device. The excellent workmanship and state-of-the-art technology of both motor and pump guarantee a smooth and energy-efficient operation of the pump in its constant underwater application.

A strainer from stainless steel protects the deep well pump from contamination, a thermal protection circuit provides overheating protection. A reliable check valve prevents conveyed water from flowing back in the pipe, thus ensuring that water is always available when required.

FULL POWER AND SLIM DESIGN

From a depth of up to 50 m, the powerful pressure of the TDP 750 E of max. 5.2 bar reliably supplies the people aboveground with up to 85 litres of clear water per minute. As the compact power pack is designed rather slim, the pump can even be used in smaller bore holes with a minimum diameter of 125 mm.

Continuous operation in water throughout the season – be on the safe side!

Once the ready-to-use-device has been lowered to the ground of the well or shaft (submersion depth of 20 metres), you'll have nothing else to worry about. The TDP 750 E offers watertight encapsulation in accordance to IPX8 type of protection and is designed for continuous underwater use. This high-quality feed pump always provides maximum safety. The operational safety of the deep well pump was tested by the inspection authority TÜV Rheinland. You only have to make sure that the pump is always completely submerged in the pumping medium and has a minimum distance of 50 cm to the bottom of the well to be protected from potential deposits near the ground.


Special equipment features of the TDP 750 E

TDP 750 E – for bore holes starting at 12.5 cm
With a diameter of only 10 cm the slim deep well pump can already be inserted in bore holes of minimally 12.5 cm. The high-quality pressure connection brass thread is designed for hoses of 1 ¼".
TDP 750 E – 1 ¼" threaded connection
The housing of the TDP 750 E is manufactured of stainless high-grade steel. The pump is further equipped with a copper motor, check valve and integrated thermal protection circuit. It is Plug & Play connected thanks to the power cable of 23 metres length.
TDP 750 E – dirt strainer
The dirt strainer is also made of stainless steel. Based on a solids content of 0.15 % in one tonne of water, it prevents the intrusion of particles sized larger than 1.8 mm and protects the pump from damages caused by sand and dust.
TDP 750 E – spacer foot
To ensure that the TDP 750 E can be attached to the ground, the optionally available spacer foot can be mounted, preventing solids from being sucked in at the inlet. However, the bottom of the well must be clean and free from dirt or contaminations.

Finding a suitable deep well pump that meets your individual requirements

The water consumption of a lawn sprinkler depends on the hose diameter and the feed pump's water pressure.

Here is a rule of thumb for determining at least an approximate water demand: A customary lawn sprinkler needs roughly 800 to 1,200 litres of water per hour*

*depending on the water pressure

The further up the deep well pump has to transport the water, the lower will be the water pressure and the maximum flow rate in litres per hour. For this reason you should make sure the pump you choose is sufficiently dimensioned. Calculate the anticipated water demand and then decide in favour of the TDP deep well pump that best meets your individual requirements.

The deep well pump TDP 5500 E transports up to 6,000 litres per hour which – depending on the delivery head – is sufficient for the simultaneous water supply of several sprinklers.

If you want to make use of a smaller number of sprinklers, but they are located further away from the well, we recommend the deep well pump TDP 7500 E – it achieves a delivery head of up to 93 metres. With a flow rate of 4,800 litres per hour it also permits a sufficient pressure level for the parallel operation of several lawn sprinklers.

The ideal supplement: Pressure switch for automatic pump control

With an electronic pressure switch you can control your water pump automatically without having to switch the pump on or off manually. The pressure switch monitors both the water pressure and the flow rate in the pipe and switches the pump connected on and off automatically when the tap or garden hose is used. In addition, the pressure switch protects the pump against running dry and in this way extends its service life. For our garden pumps of the TGP series we recommend using the electronic pressure switch TDP DSP as a convenient Plug & play solution. With their integrated mains power socket the Trotec garden pumps can be easily connected to the pressure switch using a mains plug. For Trotec's deep well pumps of the TDP series we offer the pressure switch TDP DS. Its open cable end is connected directly to the control box of the deep well pump and the pressure switch can control the water delivery automatically. Also choose reliable Trotec brand quality when you need a pressure switch!

Pressure switch TDP DSP
Pressure switch TDP DS
Deep well pumps

All Deep well pumps in direct comparison:

To find the Deep well pump which exactly meets your requirements, please consult the concise overview of all Deep well pumps from Trotec, which we're providing to you here so that you can compare them directly to each other.

Models which you do not wish to include in your comparison can be easily dismissed with only one click.

Technical data by comparison

A few practical benefits:

  • Impressive 1000 watts of power for pumping up to 5,100 litres per hour
  • Robust pressure connection with brass insert
  • Pump housing made of stainless steel
  • Maximum delivery head: 50 metres
  • Maximum pressure: 5.2 bar
  • Extremely durable thanks to rust-proof stainless steel housing and copper motor
  • Maintenance-free motor with integrated thermal protection circuit activated by overheating of the device
  • Stainless steel dirt strainer
  • IPX8 type of protection for the pump – suitable for continuous underwater use
  • With mains plug (Plug & Play)
  • Reliable check valve preventing backflow of the conveyed medium
  • 2 suspension eyes for lowering the pump
  • Trotec brand quality for deep well pumps
  • Perfect for pumping clear water from a well, rainwater cistern or shaft
  • For effortless service water supply or irrigation in your home or garden

All important features at a glance

Ground water
1,000 watts power input
Flow rate of 5,100 litres per hour
Delivery head of 50 metres
Submersion depth max. 20 m
A water level of no more than 767 mm is sufficient for starting the device
Ground water with particle sizes of up to 1.8 millimetres
The diameter of the bore hole amounts to no more than 125 mm.
1 ¼" threaded connection
Integrated backflow preventer
Cable length: 23 metres
Well water
For the application in drainage shafts

Delivery head and flow rate of the TDP 750 E

Delivery head and flow rate of the TDP 750 E

Benefit from the Trotec brand quality guaranteeing high value, safety and functionality. Via the registered GS mark the inspection authority TÜV Rheinland certifies that, if used foreseeably and as intended, the device does not pose a risk to the health and safety of the user.

Brand quality plus cost-efficiency

Reliable, powerful and suited for the most challenging fields of application:
these are some of the quality features of Trotec's deep well pumps. Thanks to their high capacity they are able to withstand the most extreme conditions. HighPerformance for demanding applications – after all, Trotec stands for brand quality and professional solutions with an excellent value-for-money ratio!

Tested for safety, TÜV GS ID 1111221093

Buy

Technical data

Technical data
General information
  Article number 4.610.000.203
Electrical values
  Mains connection 220 - 240 V/50 Hz
  Max. power input [W] 1,000
  Pump capacity [W] 750
Electric connection
  Cable length [m] 23
Performance data
  Max. conveying capacity [l/h] 5,100
  Feed pressure [bar] 5
  Grit of pump [mm] 1.8
  Solids content in water [%] 0.15
  Max. delivery head [m] 50
  Number of phases 1
  Max. water temperature [°C] 35
  Max. submersion depth [m] 20
  Minimum operating depth [mm] 767
  Speed [rpm] 2,850
  Min. drill hole diameter [mm] 125
Ambient conditions
  Ambient temperature - min. [°C] 0
  Ambient temperature - max. [°C] 35
Safety feature
  Type of protection IPX8
  Protection class I
Control box
  Connection plug CEE 7/7
Housing design
  Stainless steel
Functions and features
  ON/OFF switch
  Thermal overload protection
  Thermal overload protection [° C] 130
  Dry run protection
  Backflow preventer
  Stainless steel screws
  Use of a suspension cord
  Suitable for both permanent operation (>10h) or salt-water operation
  Continuous operation
  Threaded connection 1 1/4"
Accessories scope of delivery
  Adapter
  Suitable for hose (hose DN)
  Suitable for thread
  Tear-resistant nylon cord, 12 m
Dimensions
  Length (packaging excluded) [mm] 100
  Width (packaging excluded) [mm] 100
  Height (packaging excluded) [mm] 687
Weight
  (packaging excluded) [kg] 11
