Deep well pump TDP 370 E

High-performance 700 W stainless steel pump transports up to 5,100 l/h of clear water from depths of up to 40 m

FREE WELL WATER INSTEAD OF EXPENSIVE TAP WATER

No life without water – which makes it a precious natural resource. And if you are one of the lucky ones to have a well or water shaft on your property, you should also use this water for irrigation or at certain consumption points in the house. This is not only significantly cheaper than the water from local utility companies, but also protects the environment. By means of the stainless steel deep well pump TDP 370 E, a cost-saving service water supply will be a piece of cake. Thanks to the impressive pump capacity of 700 W and a submersion depth of max. 20 metres, the pump transports up to 5,100 litres of water per hour from a depth of up to 40 metres (max. delivery head) from wells, water reservoirs, cisterns or drainage shafts.

By the way: As the name suggests, deep well pumps are designed for delivering water from great depths. Trotec offers various deep well pumps for delivery heads between 40 m and 93 m.

Using available natural resources

Whether for an inexpensive water supply for your kitchen garden during summer, for operating lawn sprinkler systems or for watering flowerbeds and potted plants – there are many opportunities for using self-obtained service water. The stainless steel dirt strainer in the TDP 370 E deep well pump filters out any existing solid and suspended particles from the water. This way, the pumped clear water can be easily used for cleaning purposes or as complementary supply for domestic water utilisation, e.g. for washing machine or as toilet flush water.

DRINKING WATER IS A PRECIOUS RESOURCE

If you open the tap in kitchen or bathroom, you'll immediately get fresh drinking water. However, did you know that it takes many steps until water becomes purified drinking water? Suspended matter and particles causing turbidity must be removed, the water must be chemically purified and sterilised, iron and manganese have to be filtered out, the water's hardness must be reduced or increased, the water has to be desalinated, water samples must be taken, analyses have to be performed and so on. The expensive and work-intensive effort is justified, since it's about health and the water is for human consumption. However, it doesn't need all these steps to water your garden or to flush a toilet. Free well water surely is the better alternative for these purposes, but also for wallet and environment!

Trotec's deep well pumps are highly efficient submersible pressure pumps which – due to their special design and high-quality technology – can be used in drilled wells with a minimum diameter of 12.5 centimetres. For the unproblematic water transport from great depths the standard equipment contains a connection cable of 23 metres length and suspension eyes for lowering the pump into wells, cisterns, drainage shafts or similar. Like all submersible pressure pumps our deep well pumps, too, are optionally suited for either fixed installation or the mobile application at various sites.

Saving tip:
In the long run self-pumped water saves money. The investment for installing a well in your own garden (if not already present) will quickly redeem itself over the course of only a few years – depending on the individual usage intensity. Specialized well builders can help you in the planning and construction phase of your own garden well.

TOO PRACTICAL, EVEN PROVIDED WITH PLUG & PLAY SOLUTION

The 23 m underwater cable reliably supplies the compact pump with electricity and can be immediately used thanks to the Plug & Play operation. Moreover, the pump housing of the TDP 370 E is provided with two suspension eyes at the top of the device. These allow you to conveniently lower the pump into the water to be conveyed. The optionally available spacer foot that can be mounted enables to set the deep well pump into the prepared indentation in the ground, e.g. in drainage shafts or wells. However, the bottom of the well must be clean and free from dirt in this case.

Modern technology for top manufacturing

The TDP 370 E is made from premium-quality materials to allow for a long service life. The robust pressure connection with brass insert and the stable housing made of stainless steel protect the maintenance-free copper motor in continuous underwater application in frost-free months. The deep well pump comes equipped with a stainless steel dirt strainer that provides protection against the contamination with particles from a size of 1.8 mm (based on a solids content of 0.15 % in one tonne of water). Moreover, it is provided with a check valve with backflow preventer and a thermal protection circuit activated by overheating of the device.

SLIM HOUSING, HIGH PERFORMANCE

A maximum delivery head of 40 metres, a submersion depth of up to 20 metres and a high pressure of max. 3.7 bar make the pump ideal for a clear water withdrawal from great depths. Thanks to its compact and slim design, the TDP 370 E can even be used in narrow bore holes with a minimum diameter of 125 mm.

Focus on quality and safety

Certainly, combining electronics and water requires extreme caution. This is the reason why the TDP 370 E offers watertight encapsulation in accordance to the latest standards and IPX8 type of protection. It is suitable for continuous underwater use. With the TDP 370 E you are always on the safe side. The operational safety of the pump was tested by the inspection authority TÜV Rheinland. For a smooth operation, the deep well pump has to be completely submerged in the pumping medium. However, a minimum distance of 50 cm to the ground should be maintained in order to protect the pump from potential deposits at the bottom of the well.


Special equipment features of the TDP 370 E

TDP 370 E – for bore holes starting at 12.5 cm
With a diameter of only 10 cm the slim deep well pump can already be inserted in bore holes of minimally 12.5 cm. The high-quality pressure connection brass thread is designed for hoses of 1 ¼".
TDP 370 E – 1 ¼" threaded connection
The housing of the TDP 370 E is manufactured of stainless high-grade steel. The pump is further equipped with a copper motor, check valve and integrated thermal protection circuit. It is Plug & Play connected thanks to the power cable of 23 metres length.
TDP 370 E – dirt strainer
The dirt strainer is also made of stainless steel. Based on a solids content of 0.15 % in one tonne of water, it prevents the intrusion of particles sized larger than 1.8 mm and protects the pump from damages caused by sand and dust.
TDP 370 E – spacer foot
To ensure that the TDP 370 E can be attached to the ground, the optionally available spacer foot can be mounted, preventing solids from being sucked in at the inlet. However, the bottom of the well must be clean and free from dirt or contaminations.

Finding a suitable deep well pump that meets your individual requirements

The water consumption of a lawn sprinkler depends on the hose diameter and the feed pump's water pressure.

Here is a rule of thumb for determining at least an approximate water demand: A customary lawn sprinkler needs roughly 800 to 1,200 litres of water per hour*

*depending on the water pressure

The further up the deep well pump has to transport the water, the lower will be the water pressure and the maximum flow rate in litres per hour. For this reason you should make sure the pump you choose is sufficiently dimensioned. Calculate the anticipated water demand and then decide in favour of the TDP deep well pump that best meets your individual requirements.

The deep well pump TDP 5500 E transports up to 6,000 litres per hour which – depending on the delivery head – is sufficient for the simultaneous water supply of several sprinklers.

If you want to make use of a smaller number of sprinklers, but they are located further away from the well, we recommend the deep well pump TDP 7500 E – it achieves a delivery head of up to 93 metres. With a flow rate of 4,800 litres per hour it also permits a sufficient pressure level for the parallel operation of several lawn sprinklers.

The ideal supplement: Pressure switch for automatic pump control

With an electronic pressure switch you can control your water pump automatically without having to switch the pump on or off manually. The pressure switch monitors both the water pressure and the flow rate in the pipe and switches the pump connected on and off automatically when the tap or garden hose is used. In addition, the pressure switch protects the pump against running dry and in this way extends its service life. For our garden pumps of the TGP series we recommend using the electronic pressure switch TDP DSP as a convenient Plug & play solution. With their integrated mains power socket the Trotec garden pumps can be easily connected to the pressure switch using a mains plug. For Trotec's deep well pumps of the TDP series we offer the pressure switch TDP DS. Its open cable end is connected directly to the control box of the deep well pump and the pressure switch can control the water delivery automatically. Also choose reliable Trotec brand quality when you need a pressure switch!

Pressure switch TDP DSP
Pressure switch TDP DS
Deep well pumps

All Deep well pumps in direct comparison:

To find the Deep well pump which exactly meets your requirements, please consult the concise overview of all Deep well pumps from Trotec, which we're providing to you here so that you can compare them directly to each other.

Models which you do not wish to include in your comparison can be easily dismissed with only one click.

Technical data by comparison

A few practical benefits:

  • Impressive 700 watts of power for pumping up to 5,100 litres per hour
  • Robust pressure connection with brass insert
  • Pump housing made of stainless steel
  • Maximum delivery head: 40 metres
  • Maximum pressure: 3.7 bar
  • Perfect for pumping clear water from a well, rainwater cistern or shaft
  • Extremely durable thanks to rust-proof stainless steel housing and copper motor
  • Maintenance-free motor with integrated thermal protection circuit activated by overheating of the device
  • Stainless steel dirt strainer
  • IPX8 type of protection for the pump – suitable for continuous underwater use
  • With mains plug (Plug & Play)
  • Reliable check valve preventing backflow of the conveyed medium
  • 2 suspension eyes for lowering the pump
  • Trotec brand quality for deep well pumps
  • For cost-saving service water supply or irrigation purposes in the house (washing machine, toilet) or garden (lawn sprinklers, irrigation systems)

All important features at a glance

Ground water
700 watts power input
Flow rate of 5,100 litres per hour
Delivery head of 40 metres
Submersion depth max. 20 m
A water level of no more than 691 mm is sufficient for starting the device
Ground water with particle sizes of up to 1.8 millimetres
The diameter of the bore hole amounts to no more than 125 mm.
1 ¼" threaded connection
Integrated backflow preventer
Cable length: 23 metres
Well water
For the application in drainage shafts

Delivery head and flow rate of the TDP 370 E

Delivery head and flow rate of the TDP 370 E

Benefit from the Trotec brand quality guaranteeing high value, safety and functionality. Via the registered GS mark the inspection authority TÜV Rheinland certifies that, if used foreseeably and as intended, the device does not pose a risk to the health and safety of the user.

Brand quality plus cost-efficiency

Reliable, powerful and suited for the most challenging fields of application:
these are some of the quality features of Trotec's deep well pumps. Thanks to their high capacity they are able to withstand the most extreme conditions. HighPerformance for demanding applications – after all, Trotec stands for brand quality and professional solutions with an excellent value-for-money ratio!

Tested for safety, TÜV GS ID 1111221093

Buy

Technical data

Technical data
General information
  Article number 4.610.000.201
Electrical values
  Mains connection 220 - 240 V/50 Hz
  Max. power input [W] 700
  Pump capacity [W] 370
Electric connection
  Cable length [m] 23
Performance data
  Max. conveying capacity [l/h] 5,100
  Feed pressure [bar] 4
  Grit of pump [mm] 1.8
  Solids content in water [%] 0.15
  Max. delivery head [m] 40
  Number of phases 1
  Max. water temperature [°C] 35
  Max. submersion depth [m] 20
  Minimum operating depth [mm] 691
  Speed [rpm] 2,850
  Min. drill hole diameter [mm] 125
Ambient conditions
  Ambient temperature - min. [°C] 0
  Ambient temperature - max. [°C] 35
Safety feature
  Type of protection IPX8
  Protection class I
Control box
  Connection plug CEE 7/7
Housing design
  Stainless steel
Functions and features
  ON/OFF switch
  Thermal overload protection
  Thermal overload protection [° C] 130
  Dry run protection
  Backflow preventer
  Stainless steel screws
  Use of a suspension cord
  Suitable for both permanent operation (>10h) or salt-water operation
  Continuous operation
  Threaded connection 1 1/4"
Accessories scope of delivery
  Adapter
  Suitable for hose (hose DN)
  Suitable for thread
  Tear-resistant nylon cord, 12 m
Dimensions
  Length (packaging excluded) [mm] 100
  Width (packaging excluded) [mm] 100
  Height (packaging excluded) [mm] 605
Weight
  (packaging excluded) [kg] 10

 standard equipment

 optionally available

 not available
